PRODUCT【コンパクト】【コギングなし】コアレスリニアモーター LMCシリーズ
幅広い産業分野に
薄くてコンパクト、コギングがないコアレスリニアモーター。
コギングやリップル等の外乱が小さく、速度安定性を要求されるステージに適している。磁極ピッチはいずれも32mm。
■3相
■高動特性、高同期特性、高速追随性
■低慣性高加速
■扁平な形状
■コギングなし
■1固定子に複数可動子を搭載可
コギングやリップル等の外乱が小さく、速度安定性を要求されるステージに適している。磁極ピッチはいずれも32mm。
■3相
■高動特性、高同期特性、高速追随性
■低慣性高加速
■扁平な形状
■コギングなし
■1固定子に複数可動子を搭載可
LMCA仕様
連続推力連続電力ピーク推力ピーク電流固定子幅固定子長/N数
[N][Arms][N][Arms][mm][mm]
LMCA1122.2488.834S0:128mm, S1:192mm, S3:320mm
LMCA2242.3969.266S0:128mm, S1:192mm, S3:320mm
LMCA3342.11368.498S0:128mm, S1:192mm, S3:320mm
LMCA4452.11808.4130S0:128mm, S1:192mm, S3:320mm
LMCA5521.82087.2162S0:128mm, S1:192mm, S3:320mm
LMCA6621.82487.2194S0:128mm, S1:192mm, S3:320mm
LMCA7721.82897.2226S0:128mm, S1:192mm, S3:320mm
LMCA8831.83317.2258S0:128mm, S1:192mm, S3:320mm
LMCAA961.83867.2322S0:128mm, S1:192mm, S3:320mm
LMCAC1241.84967.2386S0:128mm, S1:192mm, S3:320mm
LMCB仕様
連続推力連続電力ピーク推力ピーク電流固定子幅固定子長/N数
[N][Arms][N][Arms][mm][mm]
LMCB118272834S0:128mm, S1:192mm, S3:320mm
LMCB2362144866S0:128mm, S1:192mm, S3:320mm
LMCB3542216898S0:128mm, S1:192mm, S3:320mm
LMCB47322928130S0:128mm, S1:192mm, S3:320mm
LMCB59123648162S0:128mm, S1:192mm, S3:320mm
LMCB610924368194S0:128mm, S1:192mm, S3:320mm
LMCB712825128226S0:128mm, S1:192mm, S3:320mm
LMCB814525808258S0:128mm, S1:192mm, S3:320mm
LMCBA18127248322S0:128mm, S1:192mm, S3:320mm
LMCBC2161.88647.2386S0:128mm, S1:192mm, S3:320mm
LMCC仕様
連続推力連続電力ピーク推力ピーク電流固定子幅固定子長/N数
[N][Arms][N][Arms][mm][mm]
LMCC124298834S0:128mm, S1:192mm, S3:320mm
LMCC2492195866S0:128mm, S1:192mm, S3:320mm
LMCC3732293898S0:128mm, S1:192mm, S3:320mm
LMCC49823918130S0:128mm, S1:192mm, S3:320mm
LMCC512224898162S0:128mm, S1:192mm, S3:320mm
LMCC614725868194S0:128mm, S1:192mm, S3:320mm
LMCC717126848226S0:128mm, S1:192mm, S3:320mm
LMCC819527808258S0:128mm, S1:192mm, S3:320mm
LMCCA24429778322S0:128mm, S1:192mm, S3:320mm
LMCCC293211738386S0:128mm, S1:192mm, S3:320mm
LMCD仕様
連続推力連続電力ピーク推力ピーク電流固定子幅固定子長/N数
[N][Arms][N][Arms][mm][mm]
LMCD41313.2552413260S1:120mm, SB:180mm, S2:300mm
LMCD61973.2578813380S1:120mm, SB:180mm, S2:300mm
LMCD82623.25104813500S1:120mm, SB:180mm, S2:300mm
LMCDA3283.25131213620S1:120mm, SB:180mm, S2:300mm
LMCE仕様
連続推力連続電力ピーク推力ピーク電流固定子幅固定子長/N数
[N][Arms][N][Arms][mm][mm]
LMCE41843.2573613260S1:120mm, SB:180mm, S2:300mm
LMCE62763.25110413380S1:120mm, SB:180mm, S2:300mm
LMCE83683.25147213500S1:120mm, SB:180mm, S2:300mm
LMCEA4603.25184013620S1:120mm, SB:180mm, S2:300mm
LMCEC5523.25220813740S1:120mm, SB:180mm, S2:300mm
LMCF仕様
連続推力連続電力ピーク推力ピーク電流固定子幅固定子長/N数
[N][Arms][N][Arms][mm][mm]
LMCF42283.891215.2260S1:120mm, SB:180mm, S2:300mm
LMCF63425.7136822.8380S1:120mm, SB:180mm, S2:300mm
LMCF84567.6182430.4500S1:120mm, SB:180mm, S2:300mm
LMCFA5709.5228038620S1:120mm, SB:180mm, S2:300mm
LMCFC68411.4273645.6740S1:120mm, SB:180mm, S2:300mm
LMC-EFC仕様
連続推力連続電力ピーク推力ピーク電流固定子幅固定子長/N数
[N][Arms][N][Arms][mm][mm]
LMC-EFC1373.415013.661S1:120mm, SB:180mm, S2:300mm
LMC-EFC2753.430013.6121S1:120mm, SB:180mm, S2:300mm
LMC-EFC31133.445013.6181S1:120mm, SB:180mm, S2:300mm
LMC-EFC41503.460013.6241S1:120mm, SB:180mm, S2:300mm
LMC-EFE仕様
連続推力連続電力ピーク推力ピーク電流固定子幅固定子長/N数
[N][Arms][N][Arms][mm][mm]
LMC-EFE1502.720010.861S1:120mm, SB:180mm, S2:300mm
LMC-EFE21002.740010.8121S1:120mm, SB:180mm, S2:300mm
LMC-EFE31502.760010.8181S1:120mm, SB:180mm, S2:300mm
LMC-EFE42002.780010.8241S1:120mm, SB:180mm, S2:300mm
LMC-EFE52502.7100010.8301S1:120mm, SB:180mm, S2:300mm
LMC-EFE63005.4120021.7361S1:120mm, SB:180mm, S2:300mm
LMC-EFF仕様
連続推力連続電力ピーク推力ピーク電流固定子幅固定子長/N数
[N][Arms][N][Arms][mm][mm]
LMC-EFF1775.730922.661S1:120mm, SB:180mm, S2:300mm
LMC-EFF21545.761722.6121S1:120mm, SB:180mm, S2:300mm
LMC-EFF32315.792622.6181S1:120mm, SB:180mm, S2:300mm
LMC-EFF43095.7123422.6241S1:120mm, SB:180mm, S2:300mm
LMC-EFF53865.7154322.6301S1:120mm, SB:180mm, S2:300mm
LMC-EFF64635.7185222.6361S1:120mm, SB:180mm, S2:300mm
LMC-EFF75405.7216022.6421S1:120mm, SB:180mm, S2:300mm
LMC-EFF86175.7246922.6481S1:120mm, SB:180mm, S2:300mm
LMC-EFF96945.7277722.6514S1:120mm, SB:180mm, S2:300mm
LMC-EFFA7715.7308622.6601S1:120mm, SB:180mm, S2:300mm
LMC-EFFB8495.7339422.6661S1:120mm, SB:180mm, S2:300mm
LMC-EFFC9265.7370322.6721S1:120mm, SB:180mm, S2:300mm
LMC-EFFD10035.7401222.6781S1:120mm, SB:180mm, S2:300mm
LMC-HUB仕様
連続推力連続電力ピーク推力ピーク電流固定子幅固定子長/N数
[N][Arms][N][Arms][mm][mm]
LMC-HUB1201.5806.249S1:72mm, S2:120mm
LMC-HUB2403.116012.397S1:72mm, S2:120mm
呼び型番
[1] コアレスリニアモーター LMCシリーズ
[2] 固定子高さ
A: 60mm
B: 80mm
C: 103mm
D: 86.8mm
E: 106.8mm
EFC: 50.8mm
EFE: 75.3mm
EFF: 100mm
HUB: 41.5mm
[3] モデル
S: 標準
[4] 固定子長さ
▼LMCA/LMCB/LMCC
0: 128mm
1: 192mm
2: 320mm
▼LMCD/LMCF/LMCE**
1: 120mm
B: 180mm
2: 300mm
▼LMCHUB
1: 72mm
2: 120mm
